| Attribute | Value |
|---|---|
| Make | Toyota |
| Model | 8BNCU20 |
| Forklift Type | Stand Up Counterbalance |
| Basic Capacity (lbs/kg) | 4000/1810 |
| Load Center (in/mm) | 24/610 |
| Power | Electric – 36 Volts |
| Battery Type | Lead Acid |
| Tilt – standard (forward/back) | 3.0/5.0 degrees |
| Length to Fork Face – 18.5" Battery Box (in/mm) | 70.5/1781 |
| Length to Fork Face – 21.25" Battery Box (in/mm) | 73.3/1861 |
| Height to Top of Overhead Guard (in/mm) | 88/2235 |
| Turning radius – 18.5" Battery Box (in/mm) | 58.1/1476 |
| Turning radius – 21.25" Battery Box (in/mm) | 60.8/1544 |
| Basic Right-Angle Stack Aisle Width – 18.5" Battery Box (in/mm) | 70.8/1798 |
| Basic Right-Angle Stack Aisle Width – 21.25" Battery Box (in/mm) | 73.5/1867 |
| Front Tire Size | 16.25x6x11.25 |
| Rear Tire Size | 10x5x6.5 |
| Wheelbase – 18.5" Battery Box (in/mm) | 50.4/1280 |
| Wheelbase – 21.25" Battery Box (in/mm) | 53.1/1349 |
| Total Weight w/o Battery – 18.5" Battery Box (lb/kg) | 6865/3114 |
| Total Weight w/o Battery – 21.25" Battery Box (lb/kg) | 6965/3159 |
Related Products
Mollit consequat adipisicing in commodo fugiat. Quis voluptate pariatur ex mollit exercitation.
36 Volts – 18.5" Battery Box
| Attribute | Value |
|---|---|
| Max Amp Hours | 1085 |
| Minimum Weight | 2300 lbs |
| Box Dimensions | 38.5 x 18.5 x 32.3" |
36 Volts – 21.25" Battery Box
| Attribute | Value |
|---|---|
| Max Amp Hours | 1240 |
| Minimum Weight | 2593 lbs |
| Box Dimensions | 38.5 x 21.25 x 32.3" |
Used Forklifts, Fair Prices
Looking for affordable used Toyota forklifts?
We have high-quality, ready-to-ship used forklifts at affordable prices in our 30,000 sq ft Ohio warehouse.
