| Attribute | Value |
|---|---|
| Make | Toyota |
| Model | 8BNCU18 |
| Forklift Type | Stand Up Counterbalance |
| Basic Capacity (lb/kg) | 3500/1580 |
| Load Center (in/mm) | 24/610 |
| Power | Electric – 36 Volts |
| Tilt – standard degrees (forward/back) | 3/5 |
| Length to Fork Face 16.5" Battery Compartment (in/mm) | 68.5/1741 |
| Length to Fork Face 18.5" Battery Compartment (in/mm) | 70.5/1791 |
| Turning Radius 16.5" Battery Compartment (in/mm) | 56.1/1425 |
| Turning Radius 18.5" Battery Compartment (in/mm) | 58.1/1476 |
| Maximum Travel – fwd. / rev. – full load and no load (mph/kmh) | 7.5/12.1 |
| Total Weight (without battery) 16.5" Battery Box (lb/kg) | 6625/3005 |
| Total Weight (without battery) 18.5" Battery Box (lb/kg) | 6865/3114 |
| Front Tires Size (in/mm) | 16.25 x 6 x 11.25 (413 x 152 x 286) |
| Steer Tires Size (in/mm) | 10 x 5 x 6.5 (254 x 127 x 165) (dual) |
| Battery Type | Battery Type |
| Wheelbase 16.5" Battery Box (in/mm) | 48.4/1230 |
| Wheelbase 18.5" Battery Box (in/mm) | 50.4/1280 |
Toyota 8BNCU18 Forklift Battery and Charger Information
Mollit consequat adipisicing in commodo fugiat. Quis voluptate pariatur ex mollit exercitation.
16.5" Battery Box – 36 Volts
| Attribute | Value |
|---|---|
| Compartment Dimensions – in(mm) | 38.50" x 16.50" x 32.30" |
| AH Capacity | 750 |
| Minimum Battery Weight – lb(kg) | 1980/898 |
18.5" Battery Box – 36 Volts
| Attribute | Value |
|---|---|
| Compartment Dimensions – in(mm) | 38.50" x 18.50" x 32.30" |
| AH Capacity | 875 |
| Minimum Battery Weight – lb(kg) | 2300/1043 |
