| Attribute | Value |
|---|---|
| Make | Hyster |
| Model | H80FT |
| Type | Pneumatic Tire Internal Combustion |
| Basic Capacity (lbs/kg) | 8000/3629 |
| Load Center (in/mm) | 24/610 |
| Power | LPG |
| Engine | Kubota 3.8L LPG |
| Tire Type | Pneumatic |
| Tilt – standard (forward/back) | 6/10 degrees |
| Length to Fork Face (in/mm) | 116/2946 |
| Width – standard tires (in/mm) | 55.2/1402 |
| Width – wide tread tires (in/mm) | 55.2/1485 |
| Height to Top of Overhead Guard Standard (in/mm) | 89/2260 |
| Height to Top of Overhead Guard Optional (in/mm) | 87/2193 |
| Turning radius (in/mm) | 101.2/2570 |
| Right Angle Stack (in/mm) | 121.8/3093 |
| Weight with 2-StageLFL Mast(lbs/kg) | 13274/6021 |
| Front Tire Size | 250 x 15 – 20 Ply |
| Rear Tire Size | 7.00 x 12 -14 Ply |
| Wheelbase (in/mm) | 72/1830 |
Used Forklifts, Fair Prices
Looking for affordable used Hyster forklifts?
We have high-quality, ready-to-ship used forklifts at affordable prices in our 30,000 sq ft Ohio warehouse.
Please follow and like us:
What wheel width would this unit require for the front tires. 250-15 by 7.00″ or 7.50″ ?
The front tire size is 250 x 15 – 20. Here’s the part number and the part description for the standard wheel for a single drive Hyster H80FT – Part number: HY2083531 Part Description: WHEEL – 7.50-15 3 PC RIM/FLANGE
